Ventilation Equipment Manufacture 6Inch Metal Casing Inline Duct Fan For Round Duct (DJT15U-45M)

Wholesale 6inch metal casing inline duct fan (DJT15U-45M)

▪ Casing made of high quality steel plate
▪ Backward-curved centrifugal impeller using PA66 (FR)
▪ ABS (FR) connection box
▪ External rotor motor with low temperature rise
▪ Motor is equipped with automatic reset thermal overload protection
▪ Heavy-duty ball bearing, acceptable for continuous operation of 50000h

▪ Operating temperature range20℃~50℃
▪ Insulation Class F
▪ Enclosure class IP44


E-mail: linda@nussun.com  sales@nussun.com


Wholesale 6Inch metal casing inline duct fan (DJT15U-45M)


Metal duct fan from a vast selection of inline fan provides an excellent way to quietly ventilate a home with multiple rooms. Inline Metal duct fan is a direct drive inline cabinet fan. These Metal duct fans are designed for clean air applications where low sound levels are required. It is possible to replace a traditional ceiling-mount bathroom fan with a new inline Metal duct fan.Online shopping for inline exhaust fan and more inline fan from www.nussun.com. Find top inline Metal duct fan here at everyday low prices.

Features

1.CE  Metal casing inline duct fan

2.Pretty price of Metal casing inline duct fan

3.20 days delivery
4.3 years warranty
5.No MOQ FOR Metal casing inline duct fan



Casing made of high quality steel plate
Backward-curved centrifugal impeller using PA66 (FR)
ABS (FR) connection box
External rotor motor with low temperature rise
Motor is equipped with automatic reset thermal overload protection
Heavy-duty ball bearing, acceptable for continuous operation of 50000h

Operating temperature range20℃~50℃
Insulation Class F
Enclosure class IP44


 Performance parameter

Dimension Table (mm)

 Feature parts details

1. Casing uses high-quality steel plate, surface dustig processing

2.External optimization design ABS(FR) connection box

3. NSK ball bearing, acceptable for long time operation

4.External rotor motor with low energy consumption



Nussun, ventilation equipment duct fans manufacturer

Factory production Process

ventilation fans factory workshopNussun, offer ventilaiton duct fansventilaiton inline duct fans for home and commercialCE, UL, ETL, RoHS, CCC certificationventilation equipment and fans exhibitionVentilation inline duct fans factory
